| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | XINHENG |
| Automatic Grade: | Automatic |
| Type: | Horizontal |
| Condition: | New |
| Certification: | 1year |
| Weight: | 3200kg |
| Dimension(L*W*H): | 2500*1600*1740 |
| Power(W): | 7.5KW |
| Voltage: | 220V/380V |
| Model Number: | AD15P |
| Place of Origin: | China (Mainland) |
| Max. Swing Diameter: | 460mm |
| CNC or Not: | CNC |
| Name: | Piston Professional Production Lathe |
| Color: | Customized Option |
| Spindle bore: | 38mm |
| Warranty: | 12 Months |
| Spindle speed: | 3000rpm |
| Precision: | High Precision Machine |
| Main power: | 7.5KW |
| Max.turning length: | 400mm |
Quick Details
Specifications
High Speed Piston Professional Production Lathe CNC Cheap Price
the machine is equipped with Japan FANUC31i high-end CNC system; feed system uses high-precision ball screw, roller linear guide and high-precision grating size; dual linear servo motor-driven tool holder; make the machine has a fast response, high speed, processing High precision, suitable for high-grade piston processing.
Detail Images
ITEM |
UNIT |
ADG15P |
Capacities | ||
Max.External dia. |
mm |
150 |
Max.Length |
mm |
160 |
Max.Turning dia. |
mm |
150 |
Max.Turning length |
mm |
160 |
Spindle | ||
Spindle speed |
R/min |
4000 |
Spindle nose |
|
A2-6 |
Spindlle bore |
|
MT-5 |
Min.Indexing |
0.001 | |
Feed motion | ||
Travel of Y-axis |
mm |
16 |
Travel of X-axis |
mm |
150 |
Travel of Z-axis |
mm |
280 |
X/Z/B rapid speed |
M/min |
12/12/12 |
Tailstock | ||
Tailstock speed |
R/min |
4000 |
Quill dia. |
mm |
85 |
Quill taper hole |
|
MT-3 |
Quill travel |
mm |
260 |
Accuracy |
mm |
0.001 |
Advantages
Easy operation Reasonable structure Attractive price
High precision Maintenance simple Automatic control
Company Information
is a large professional manufacturer of LATHE, CNC LATHE, PIPE THREAD LATHE, SPHERE TURNING LATHE etc.
Our factory has 60 years experience in machine tool production.and our machine tools have been exported to more than 50 countries.
