Dimmable 10W G53 GU10  led COB AR111 spotlight AC/DC12V  AR111 ES111 spotlight lamp RA>80 COB 10W AR111 ceiling lamp



12V 10w dimmable COB led AR111 spotlight

SPECIFICATION:
Rated Power: 10W
Holder: G53
Material: Aluminum fin
Deminsion: φ111xH70mm
LED Source:Epistar
LED Quantity: Epistar 10W COB
Luminous of LED: 100-110Lm /w
Luminous Flux of Lamp: 950-1050Lm
CRI (Ra)>80
Color Temperature: 2700-6500K
Beam Angle: 30° 60°

Lifespan: 50, 000Hours



Advantage:

1.Advantage  heat sink: 1\ with 1060 pure aluminium heat body materials, heat transfer thermal effect is good, use buckle FIN process, patent technology design and manufacture

2\ Aluminum plate and cooling the body contact area and increase the close contact with seamless, reduce the air thermal resistance, speed up the aluminum plate heat conduction speed

3\ Overall larger area than traditional cooling profiles or car aluminum die-casting, die-casting thermal coefficient is twice lamp cup, is 1.5 times the car's aluminum lamp cup, LED lighting is the ideal solution for cooling, but also the future of LED lighting mainstream development direction of the radiator.

2. Up to 70% energy saving

3. Resistant to shock and vibration

4. Designed to last at least 5, 0000 hours

4. With clear and soft light
5.  2-year warranty



Applications:

1. Illumination lighting for homes, offices, restaurants, hotels, hall, chamber, villa and other slap-up locations.
2. Task lighting for store revelation, showcase, restaurant and other indoor decorations where need lighting.
3. Display lighting for the articles in stores and shops.
4. Back lighting for adverting boards.



Model Name	YN-AR111-10w
Power	10W
Input voltage	AC85-265V
Lumen	950-1050lm,
Color temperature	2700~3300k(warm white)
	3500~5000k(pure white)
	6000-6500K (cool white)
Size	111*70mm
PF	>95%
CRI	80
Certificate	CE, RoHS, LVD
Lifetime	50000hors
Storage temperature	-25ºC to + 65ºC
Operating temperature	-40ºC to + 55ºC
IP rate	IP20
Led brand	Epistar
Base	G53
