After-sales Service Provided: | Engineers available to service machinery overseas |
---|---|
Condition: | New |
Brand Name: | Mingling |
Weight: | 180KG |
color: | White |
Model Number: | MLK-326H |
Place of Origin: | China (Mainland) |
Application place: | factory |
Stitch style: | lockstitch |
Applicatable material: | thickness material |
Needle number: | Single needle |
Delivery package: | Standard Sea Worthy Cartoon Packing |
Sewing area: | 220*100mm |
Quick Details
Specifications
1.Brief introduction:
Highest sewing speed 2800 stitches /min using sittch (3.0mm)
Increased high penetration force
Low power consuption
Easily and accurately positioning of cloth
Easily transformation of sewing pattern
Set to large capacity of memory
High accuracy,easy-to-use LCD touch operation panel
to realise low tension stable sewing
High speed sewing and perfect stitch appearance,sewing apeed of up to 2800/rpm,energy saving and the same time achieved excellent quality and production efficiency.
Beautiful stitch sewing
the overlapping part event hough in material,also can make the bottom thread tightness consistent
without tilting the machine head can be adjusted by dricing a needle guard
Awide field of vision is clearly visible
2.Specification:
Highest sewing speed 2800 stitches /min using sittch (3.0mm)
Increased high penetration force
Low power consuption
Easily and accurately positioning of cloth
Easily transformation of sewing pattern
Set to large capacity of memory
High accuracy,easy-to-use LCD touch operation panel
to realise low tension stable sewing
High speed sewing and perfect stitch appearance,sewing apeed of up to 2800/rpm,energy saving and the same time achieved excellent quality and production efficiency.
Beautiful stitch sewing
the overlapping part event hough in material,also can make the bottom thread tightness consistent
without tilting the machine head can be adjusted by dricing a needle guard
Awide field of vision is clearly visible
2.Specification:
Item | MLK-H3020RR |
Stitching type | Single needle lockstitch |
Hook type | Semi rotary large shuttle hook |
Sewing area | 300*200mm |
Maximum sewing speed | 2000 stitches/pattern |
Feed method | Intermittent/Continuous(switch over mehod) |
Stitching pitch | 0.1mm-20mm(resolution 0.1mm) |
Maximum no.of stitches | 20000 stitches/pattern |
Maximum no.of stored patterns | 520 patterns(control panel internal memory) |
Enlargement/reduction function | 10 to 200% for both X and Y axis(variable in 0.1% steps) |
Memory mdium | USB flash memory(not included with sewing machine)(USB-connected FDD can also be connected) |
Total weight | 168.5kg |
Clamp holder method | 30mm |
Work holder method | Pneumatic |
Chuck device | Special specification |
Presser foot lift stroks | 15-18mm two level adjustment |
Presser foot stroks | 4-10mm |
Spindle motor | MINGLING electric 750w direct servo motor |
Applicable needle | Dpx17#18(standard) |
Operation panel | 5.7'' LCD touch panel,white LED backlight |
Outline dimension | 1200*1068*1230mm(excluded thread stand) |
Power supply | 220-240V,single-PE 110-120V, 380-415(option unit required) |
