Technical parameters
| Item |
MLK-H6030R |
| Stitching type |
Single needle lockstitch |
| Hook type |
Shuttle hook |
| Sewing area |
600*300mm |
| Maximum sewing speed |
2500-2800 stitches/pattern |
| Feed method |
Intermittent/Continuous(switch over mehod) |
| Stitching pitch |
0.1mm-12.7mm(resolution 0.1mm) |
| Maximum no.of stitches |
20000 stitches/pattern |
| Maximum no.of stored patterns |
999 patterns(control panel internal memory) |
| Enlargement/reduction function |
10 to 200% for both X and Y axis(variable in 0.1% steps) |
| Memory mdium |
SD/USB flash memory(not included with sewing machine)(USB-connected FDD can also be connected) |
| Total weight |
440kg |
| Clamp holder method |
38mm |
| Work holder method |
Pneumatic |
| Chuck device |
Special specification |
| Presser foot lift stroks |
3-15mm two level adjustment |
| Presser foot stroks |
3-15mm |
| Spindle motor |
MINGLING electric 750w direct servo motor |
| Applicable needle |
Dpx17#18(standard) |
| Operation panel |
5.7'' LCD touch panel,white LED backlight |
| Outline dimension |
1351*1572*1234(excluded thread stand) |
| Power supply |
220-240V,single-phase 110-120V, 380-415(option unit required) |
Sewing speed wil be affected by the operation,material and fixture weight factors due to different.
