Type: | Coding Machine |
---|---|
After-sales Service Provided: | No overseas service provided |
Packaging Material: | Paper |
Brand Name: | AutoPack |
Application: | Hot Ink Roll |
Type: | Hot Ink Roll |
Dimension(L*W*H): | (L)120 (W)165 (H)185mm |
Power: | 110 or 220VAC, 50/60Hz |
Voltage: | 200W |
Driven Type: | Electric |
Packaging Type: | Bags |
Model Number: | PR-200 |
Place of Origin: | Taiwan |
Condition: | New |
Consumption material: | Hot ink roll , 32 x 36mm |
haracter size: | 3mm for T-type, 3mm or 5mm for R- type |
Quick Details
Specifications
FEATURES:
- Suit for HFFS, VFFS and continuous packaging machines
- Driven by stepping motor
- Coding detected by encoder accurately
- Microprocessor program
- Digital LED control panel, and automatic temperature feedback control system
- Hot ink dry instantly on contact with substrate
- Multiple and quick changeover printing head for R&T types
- 3mm & 5mm brass types for clear printing
- Easy adjustment of coding area with 9 digits x 14 lines
- Including aluminum mounting bracket
- Max liner speed to 35M/min (standard)
OPTIONS:
- Servo motor
- Ink roll pre-warmer
SPECIFICATIONS:
- Power: 110 or 220VAC, 50/60Hz, 200W
- Signal required: Contact signal,NPN photoelectric sensor or limit switch
- Printing speed: Liner speed is up to 35M/min
- Minimum printing distance: 120mm (40mm is possible)
- Minimum package length: 40mm for T-type, 80mm for R-type
- Character size: 3mm for T-type, 3mm or 5mm for R- type
- Print area: 1-14 lines * 14 digits
- Consumption material: Hot ink roll, 32 x 36mm
- Dimension: Size of printer (L)120 (W)165 (H)185mm
(for reference only, the real drawing should be considered as final.) - Size of control box (L)190 (W)70 (H)220mm
AutoPack Co., Ltd.
Filling/Capping/Coding/Labeling/Tablet Counting/Turnkey System/Automation
