| Brand Name: | AutoPack |
|---|---|
| Name: | TC-100 |
| Certificate: | no |
| Weight: | nope |
| Usage: | packaging machine |
| Model Number: | TC-100 |
| Place of Origin: | Taiwan |
| Packaging Material: | Glass,Plastic |
| Packaging Type: | Other,Capsule,Tablet |
| Application: | Chemical |
| Condition: | New |
| After-sales Service Provided: | No overseas service provided |
| Dimension(L*W*H): | (L)760mm (W)550mm (H)740mm |
| Power: | Single Phase 110 or 220VAC |
| Voltage: | 50/60Hz |
| Driven Type: | Electric |
Quick Details
Specifications
FEATURES:
- PLC control system. Easy operation by Touch screen
- Highly accurate Counting Speed: 600-1000pcs/min
- Flap Nozzle for Non-Stop counting
- Dust Accumulating device enhance the counting accuracy
- Japan made "Keyence" high accuracy fiber sensor
- Tool Free for counting all types tablets and capsules
- Easy control variable counting speed
- Memory slot for counting recall
- Advanced stainless steel GMP design
- Choice of funnel sizes to suit container neck
- Easy manual adjustment of hopper
SPECIFICATIONS:
- Speed: 600-1000 pcs/min
- Tablet Size 5mm 160,000 Tablets / hour
- Tablet Size 10mm 90,000 Tablets / hour
- Capsule Size # 1 50,000 Capsules / hour
- Capsule Size # 4 70,000 Capsules / hour
- Bottle size: 30~200mm in diameter
- Accuracy: ±0.1-0.2%
- Power Supply: Single Phase 110 or 220VAC, 50/60Hz
- Machine Dimensions: (L)760mm (W)550mm (H)740mm
(for reference only, the real drawing should be considered as final.)
