| Type: | Laminating Machine |
|---|---|
| Automatic Grade: | Automatic |
| Packaging Material: | |
| Packaging Type: | |
| Application: | |
| Condition: | New |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | CE |
| Weight: | 4800kg |
| Dimension(L*W*H): | 11500*2200*2400 |
| Model Number: | YB-1450E |
| Brand Name: | Youbond |
| Place of Origin: | China (Mainland) |
| Power: | 22kg |
| Voltage: | 380v/50hz |
| Driven Type: | Manual |
| Max sheet size: | 1450*1250mm |
| Min sheet size: | 500*500 |
| Accuracy: | 1mm |
Quick Details
Specifications
YB-1300/1450/1650E Automatic flute laminating machine
Brief Introduction
Specification
Model |
YB-1300E |
YB-1450E |
YB-1650E |
Max Sheet |
1300*1250mm |
1450*1250mm |
1650X1450mm |
Min Sheet |
400X400mm |
400X400mm |
400X400mm |
Top Paper Thickness |
150GSM-600GSM |
150GSM-600GSM |
150GSM-600GSM |
Max Speed |
7000sheets/hour |
7000sheets/hour |
7000sheets/hour |
Fitting Precision |
1.5mm |
1.5mm |
1.5mm |
Measurement |
11.5*2*2.4M |
11.5*2.2*2.4M |
11.5*2.2*2.4M |
Machine Weight |
5000kg |
5500kg |
6000kg |
Machine Power |
10KW/380V |
11KW/380V |
12KW/380V |
Bottom Paper Thickness |
A,B,C,E,F,AB,BB,BC,EE/ Corrugated paper/ Industry coardboard | ||
