| Brand Name: | NS |
|---|---|
| Size: | 3x3-7x7mm |
| Type: | NSP-B |
| Material: | LBO |
| Color: | colorless |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Feature:
Water Cooling medium, the laser beam performance is more stable
the Ability to resist laser damage is stronger
for high Power laser system
Specification of Q- Switch:
Items |
NSP-B-3 |
NSP-B-4 |
NSP-B-5 |
NSP-B-6 |
NSP-B-7 |
Clear Aperture diameter, mm |
2.6 |
3.6 |
4.6 |
5.6 |
6.6 |
Crystal Size, mm |
3x3x20 |
4x4x20 |
5x5x20 |
6x6x20 |
7x7x20 |
Quarter Wave voltage(@1064 nm), kV DC |
1.8kV |
2.4kV |
3.0kV |
3.4kV |
4.0kV |
Capacitance, PF |
<5 |
<5 |
<5 |
<5 |
<5 |
Contrast Ratio |
>30dB |
>30dB |
>30dB |
>30dB |
>30dB |
Single Pass insertion loss@1064nm |
<1.5% |
<1.5% |
<1.5% |
<1.5% |
<1.5% |
Cell Size, mm |
f60x/76 |
f60x76 |
f60x76 |
f60x76 |
f60x76 |
Damage Threshold, @1064nm, 10HZ, 10ns |
10J/cm2 | ||||
