| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 year |
| Certification: | CE |
| Brand Name: | Allfine Group |
| Condition: | New |
| Weight: | 500KGS |
| Dimension(L*W*H): | 3.5x1.72x1.63m |
| Power(W): | 2.7kw |
| Voltage: | 220V, 2Phase, 50Hz |
| Model Number: | LC-1400FDS |
| Place of Origin: | China (Mainland) |
| Material: | Plastic |
| Bag Type: | Patch Bag |
| Machine Type: | Sealing Machine |
| Single-Sided Thickness Of Film: | 0.008-0.15mm |
| Max Bag Making Width: | 100-700mm |
| Name: | OPP BOPP DPP PE Ultrasonic Welding plastic side sealing bag making machine |
Quick Details
Specifications
OPP BOPP DPP PE Ultrasonic Welding plastic side sealing bag making machine
HD video link about LC-1400FDS film folding and side sealing machine
HD video link about LC-PE tube film side gusseting machine edge Inserting machine
================================================================
HD video link about LC-600 Plastic T-shirt bag making machine
Https://youtu.Be/ZpTga-G8xzI
================================================================
HD Video link about LC-45 mini type film blowing machine
Https://youtu.Be/d1BY1mQprn0
HD Video link about LC-1500 PE film blowing machine extruder (1500mm width, export to Bangladesh)
Https://youtu.Be/ahjr26sz_aI
Video link about PE film blowing machine (800mm width)
Https://youtu.Be/u1fE5WYQtNw
Video link about PE film blowing machine (1500mm width)
Https://youtu.Be/UZE33UWpzSc
================================================================
Flexo printing machine (6 colors, 1000mm width, 60m/min printing speed)
Https://youtu.Be/1x1PsG66ecI
================================================================
| Usage |
this machine is one part of the thermal cutting machine set, suitable for folding BOPP sheet with such functions as automatic gluing, organ-type bottom folding, pearly-lustre film laminating, hobbing and longitudinal sealing (used together with supersonic generator) and opening breaking of roll material. (The opening breaking mechanism can be equipped separately.)
|
| Optional Devices |
1. Ultrasonic Sealing Device
|
Main specification
| Model | LC-1200FDS | LC-1400FDS | LC-1600FDS | LC-2000FDS |
| Max unwinding width | 1200mm | 1400mm | 1600mm | 2000mm |
| Max rewinding width | 600mm | 700mm | 800mm | 1000mm |
| Max material diameter | 500mm | 500mm | 500mm | 500mm |
| Rewinding speed | 80m/min | 80m/min | 80m/min |
80m/min |
| Heating power | 200w | 200w | 200w | 200w |
| Ultrasonic power | AC1000VA | AC1000VA | AC1000VA | AC1000VA |
| Power supply | AC220V/50Hz | AC220V/50Hz | AC220V/50Hz | AC220V/50Hz |
| Total power | 2.5kw | 2.7kw | 3kw | 3kw |
| Fold shelf | 1.49x1.52x1.37m | 1.59x1.72x1.63m | 1.7x1.92x1.78m | 1.89x2.2x2.1m |
| Rewinder | 1.88x0.82x1.2m | 1.88x0.92x1.2m | 1.88x1.02x1.2m | 1.88x1.22x1.2m |
| Double folder dimension | 2.32x0.82x1.2m | 2.32x0.92x1.2m | 2.32x1.02x1.2m | 2.32x1.22x1.2m |
