Technical Parameters

Configuration

Effective pixels

3 Mega Pixel

Optical Zoom

X18

Video Resolution

1920 X1080/30fps

Zoom Focus

F=4.85-82mm

Focus Time

< 1 S

Outlet

HDMI MINI/AV

Infrared Laser Wavelength

808+-5nm( Wavelength available from 808nm-980nm)

Laser Chip

Optical Power 3 W

IR Angle

Electric synchronized zoom 68-1.5 continuously adjustable

Zooming time

2 S

IR Range

Far corner:500m; near angle:80m

IR Area

7.85 m SF when 360Lighting

Brightness Settings

Manual/Auto

Storage

32GB SD

Communication Control

S.BUS Control

Power

12V DC

Maximum Power

25W

Axis Angel

Horizontal:0- +357; Vertical:-15- +90;

Stability Accuracy

0.2 Mrad(RMS)

Storage Temperature

-40C~+80C

Working Temperature

-20C~+55C

Overall Dimension

Height: 206mm; POD Diameter:150mm

Weight

1.5kg
