| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | Sanmore |
| Automatic Grade: | Automatic |
| Type: | Horizontal |
| Condition: | New |
| Model Number: | CK600 |
| Place of Origin: | China (Mainland) |
| Max. Swing Diameter: | 600 |
| CNC or Not: | CNC |
Quick Details
Specifications
Specifications & Model |
CK600 |
Max. Swing dia. over bed |
630 Mm |
Max. Swing over cross slide |
400mm |
Max Machining length |
850mm (1500mm optional) |
Spindle Head type |
A2-8 |
Dia. of spindle bore |
82 Mm |
X/Z Axis repeat positioning accuracy |
0.01mm |
Max Travel of X axis |
320 Mm |
Max Travel of Z axis |
920mm |
X Axis rapid feed |
10m/min |
Z Axis rapid feed |
10m/min |
Maximum Speed of spindle |
100-1000 R/min |
Tailstock Quill diameter |
75mm |
Tailstock Quill travel |
110mm |
Tailstock Quill taper |
Morse No.5 |
Type of cutter frame |
4-position electric tool post |
Main Motor power (frequency conversion) |
11kw |
Machine Overall size |
2940*1400*1720mm |
Machine Weight |
2900kg |
