| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | Sanmore |
| Automatic Grade: | Automatic |
| Type: | Horizontal |
| Condition: | New |
| Model Number: | CK0640 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Specifications & Model |
CK0640 |
Max. Swing dia. over bed |
300 Mm |
Max. Swing over cross slide |
100 Mm |
Max Machining length |
320mm |
Spindle Head type |
A2-5 |
Dia. of spindle bore |
48mm |
through-hole Diameter of drawn pipe |
40mm |
X/Z Axis repeat positioning accuracy |
0.01mm |
Max Travel of X axis |
300 |
Max Travel of Z axis |
380 |
X Axis rapid feed |
5m/min |
Z Axis rapid feed |
10m/min |
Maximum Speed of spindle |
150-2000r/min |
Tailstock Quill diameter |
52mm |
Tailstock Quill travel |
90mm |
Tailstock Quill taper |
Morse No.3 |
Type of cutter frame |
4-position electric tool post/Gang-type tool post Optional |
Main Motor power (frequency conversion) |
4KW |
Machine Overall size |
1560*1070*1740mm |
Machine Weight |
1000kg |
