| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | Sanmore |
| Automatic Grade: | Manual |
| Type: | Horizontal |
| Condition: | New |
| Model Number: | CK6136 |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
Quick Details
Specifications
Specifications & Model |
CK 6136 |
Max. Swing dia. over bed |
360mm |
Max. Swing over cross slide |
190mm |
Max Machining length |
750mm |
Spindle head Type |
A2-6 |
Dia. of Spindle bore |
58 mm |
through-hole Diameter of drawn pipe |
50mm |
X/Z Axis repeat positioning accuracy |
0.01mm |
Max travel of X axis |
300 mm |
Max travel of Z axis |
520(optional 750mm) |
X axis rapid Feed |
5m/min |
Z axis rapid Feed |
10m/min |
Maximum Speed of spindle |
150-2000 r/min |
Tailstock Quill diameter |
60mm |
Tailstock Quill travel |
100mm |
Tailstock Quill taper |
Morse No.4 |
Type of cutter Frame |
4-position Electric tool post |
Main Motor power (frequency conversion) |
5.5kw |
Machine Overall size |
1950*1200*1750mm |
Machine weight |
1560 kg |
