| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | Sanmore |
| Automatic Grade: | Automatic |
| Type: | Horizontal |
| Condition: | New |
| Model Number: | CK6150 |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
Quick Details
Specifications
Specifications & Model |
CK 6150 |
Max. Swing Dia. over bed |
520mm |
Max. Swing over cross slide |
250mm |
Max Machining length |
850mm (1500mm optional) |
Spindle head Type |
A2-8 |
Dia. of Spindle bore |
82mm |
X/Z Axis repeat positioning accuracy |
0.01mm |
Max travel of X axis |
300mm |
Max travel of Z axis |
920mm |
X axis rapid Feed |
10m/min |
Z axis rapid Feed |
10m/min |
Maximum Speed of spindle |
100-1000r/min (1501500 high speed) |
Tailstock Quill diameter |
75mm |
Tailstock Quill travel |
110mm |
Tailstock Quill taper |
Morse No. 5 |
Type of cutter Frame |
4-position electric tool post |
Main Motor power (frequency conversion) |
7.5kw |
Machine Overall size |
2940*1300*1680 |
Machine weight |
2800kg |
