| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | Sanmore |
| Automatic Grade: | Automatic |
| Type: | Horizontal |
| Condition: | New |
| Model Number: | LS450 |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
Quick Details
Specifications
Specifications and Model |
LS450 |
Max swing diameter over bed |
450mm |
Max swing over cross slide |
120mm |
X-axis rapid travel |
380mm |
Z-axis rapid travel |
300mm |
Spindle |
A2-5 |
Max Spindle Speed |
4500r/min |
Chuck form |
Collet chuck (Six inch chuck) |
Spindle go-bore dia |
56mm |
Drawing pipe go-bore dia |
46mm |
Types Cutter frame |
Comb-type tool post |
X/Z-axis repeatability |
0.01mm |
X-axis rapid traverse |
20m/min |
Z-axis rapid traverse |
20m/min |
Main motor |
5.5kw |
Overall side |
3550*1600*1800 |
Machine weight |
3980kg |
