| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | Sanmore |
| Automatic Grade: | Automatic |
| Type: | Horizontal |
| Condition: | New |
| Model Number: | MTC450 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Specifications & Model |
MTC450 |
Max. Swing dia. over bed |
450 Mm |
Max swing over gap |
120mm |
Max Travel of X axis |
380 Mm |
Max Travel of Z axis |
300 Mm |
Spindle Head type |
A2-5 |
Maximum Speed of spindle |
5000r/min |
Type of chuck |
Six Inch chuck/collet |
Dia. of Spindle bore |
56mm |
through-hole Diameter of drawn pipe |
46mm |
Type of cutter frame |
Gang-type Tool post |
X/Z Axis repeat positioning accuracy |
0.005 Mm |
X Axis rapid feed |
25 M/min |
Z Axis rapid feed |
25 M/min |
Main Motor power (frequency conversion) |
Servo 5.5 Kv |
Machine Overall size |
2080*1500*1700mm |
Machine Weight |
1750kg |
System Optional:
the Following systems may be selected:
1. FANUC CNC SYSTEM; 2. SIEMENS CNC SYSTEM; 3. MITSUBISHI CNC SYSTEM; 4.GSK CNC SYSTEM; 5. RAPID CNC SYSTEM;6. KND CNC SYSTEM; 7. PRECISION SYSTEM; 8. SYNTEC CNC SYSTEM
