Rotary Satellite combination flexo printing press PVC OPP BOPP PE NY PET CPP Paper adhesive sticker ect

Design source:
Based on the video and images and requirements provided by Italian customers, it absorbs the elements of flexographic printing presses, It is the Italy-China jointly developed Satellite combination flexographic printing press.

Features:

1.from the unwinding to rewinding be a very short distance, only 6.8 meters.

2.Self-developed special scraper to make up for high-speed flying ink, reducing the solvent in the air of volatilization.

3.Repeated printing length is 203-635MM, to make up the disadvantage of printing length no enough of laminated flexo printer.

4.Using satellite rotary machine for color register, color register will be high precision, printing stability.

5.Suit for Printing material: PVC: 35 to 70 m OPP: 20 to 70 m BOPP: 20 to 60 m PE: 35 to 100 m NY: 20 to 50 m PET: 20 to 60 m CPP: 20 to 60 m Paper: 20 to 250 g / Other materials.

6.the period of plate made is short, the cost is low, the period of multi-color gravure cylinder is 5-10 days, but the flexography is 5 hours. the flexography depends on the printing area and the size of the plate, which is much lower than the cost of gravure cylinder.

7.Pre-heat before printing, the wind knife drying design after printing. Solve the problem of too short for every printing unit of satellite printing press, easier to dirt the ink when it going to dry.

8.1-6 color can be customized according to requirement, width 300-1600 customized according to need

9.Sections:1 unwinding, 2 automatic constant tension, 3 special scraper, 4 printing unit, 5 traction, 6 automatic constant tension, 7 rewinding

Main Technical Specification:

Model of machine	YT-600	YT-800	YT-1000
Width of Printing	600mm	800mm	1000mm
Printing Speed	10-200m/min	10-200m/min	10-200m/min
Accuracy	<0.05mm	<0.05mm	<0.05mm
Length of Printing	203-635mm	203-635mm	203-635mm
Diameter of Roll	900mm	900mm	900mm
Total Power	16kw	18kw	20kw
Dimension	3000x2000x1600mm	3000x2400x1850mm	3000x2600x1850mm
