| Brand Name: | KIMKOO |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Warranty: | 2 years |
| Certification: | CE, ISO9001 |
| Weight: | 2500KG |
| Dimension(L*W*H): | lenght 3.2m, width 1.6m, height 1.8m |
| Voltage: | 3AC380V |
| Model Number: | JK-PS-65 |
| Place of Origin: | China (Mainland) |
| Condition: | New |
| Productivity: | 65 rows/min |
Quick Details
Specifications
Automatic Mini Pocket Spring Coiling Machine
Main Technical Parameters
this Automatic Mini Pocket Spring Machine is with micro-computer. Self-developed control system,ultrasonic welding, low noise, no pollotion, the best choice for the production of pocket spring.
1. Microcomputer control is commonly employed and mechanical structure with high precision and no-cylinder devices ensure materials saving,
Labor saving and energr saving, guaranteeing simple operation and easy learning and understanding.
2. Delivery system control precisely by splitter, position accurately.
3. Spring compression and delivery by Servo control, simple and accurate action.
4. Springs making are all Servo control, convenient adjustment.
5.Automatic counting in system; record daily production output automatically.
6. It produces good shape center-welded pocket springs with small MID-coil diameter.
Main Technical Parameters
| Productivity | 65 rows/min |
| Mechanical Principle | Mechanical drive |
| Torsion Machine | Two-axis numberical control torsion machine head |
| Shape of Spring | Straight spring and drum-type spring |
| Demand of Gas Supply | 1.0m/min |
| Working Pressure | 0.5-0.6mpa |
| Total Pressure | 23KW |
| Input Voltage | 3AC380V |
| Input Current | 55A |
| Frequency | 50/60 Hz |
| Weight | 2500KG |
| Thickness of Non-Woven Fabric | 50-90gm/ |
| Width of Non-Woven Fabric | 300-580mm |
| Diameter of Steel Wire | 1.0-1.6mm |
| Diameter of Spring Core | 35-50mm |
| Spring Height | 60-200mm |
| Size | Lenght 3.2m, width 1.6m, height 1.8 |
this Automatic Mini Pocket Spring Machine is with micro-computer. Self-developed control system,ultrasonic welding, low noise, no pollotion, the best choice for the production of pocket spring.
1. Microcomputer control is commonly employed and mechanical structure with high precision and no-cylinder devices ensure materials saving,
Labor saving and energr saving, guaranteeing simple operation and easy learning and understanding.
2. Delivery system control precisely by splitter, position accurately.
3. Spring compression and delivery by Servo control, simple and accurate action.
4. Springs making are all Servo control, convenient adjustment.
5.Automatic counting in system; record daily production output automatically.
6. It produces good shape center-welded pocket springs with small MID-coil diameter.
