1. Introduction

 BC-PT2 Pitot Tube Gas Velocity/Temperature/Pressure Measurement is designed by the principle of differential pressure measurement of pitot tube. the velocity, temperature and pressure of gas with high temperature and high humidity, from different kinds of boiler, furnace flue, and mine exhaust pipe, can be monitored on line.

2. Features

 All-in-one design. Display unit and purge control are integrated in the anti-raining box.

 with LED display.

 A simple operation

 Adopts 316L stainless steel

 with three of 4-20mA output

3. Specifications

 Pitot tube material: stainless steel 316L

 Pitot tube insertion length: 1500mm or customized length

 Velocity measurement range: 0-30m/s or optional

 Measurement accuracy:  5%FS

 Calibration frequency: 6 months

 Temperature detecting range: (0~300)  or custom range

 Pressure detecting range: (-10~10) kPa/ (-5~5) kPa

 the medium temperature range: (0~300)

 Environment temperature: (-20~50)

 Relative humidity90%;

 Installation: DN65,PN6 flange connection

 with purging and control unit: 4 hours automatically purging (time adjustable)
