GM Series High Speed Automatic Rotary Paper Sheeting Machine

Features:

GM model Servo Precision high speed sheet cutter apply the advanced technical of Germany and England. the machine computer control system apply Servo motor and AC transducer which are both international of Top brand. the conveyer belt apply NITTA from Japan.the pneumatic vibrator apply FINDEVA from Switzerland. the electrical system adopts SCHNEIDER & OMRON, the speed of cutting paper is so fast and stable. Germany precise bearing and cutting knife assure the high cutting precision. the touch screen makes the operation easy. the anti-curve rack assure the paper flat. this machine is the paper processing machine which is very popular in the paper making and printing industry. It can improve the efficiency and benefit of your work.

Technical Parameter:

Model	GM-1900(1100,1400,1700 size for choose)
Model of Cutting Paper	the up knife cut reciprocally and the down knife is fixed
Thickness of Cutting Paper	60-550g
Cutting Precision	the cutting length<1000mm:+/-0.5mm; the cutting length>1000mm:+/-0.1%
Max. Cutting Speed	350cuts/min
Gross Weight	17000kgs
Power Consumption	380V/50HZ/3PH
Max. Cutting meter speed	350m/min
Cutting length range	450-1600mm
Paper piling height	1500mm
Max. Scroll diameter	1800mm(71'') Max
Max. Paper-cutting width	1900mm
the format of slitting	2 reel
the request for air compressor	0.8 Mpa
