| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 year |
| Voltage: | 380V,3P.50HZ |
| Brand Name: | Allfine |
| Condition: | New |
| Weight: | 2600kgs |
| Dimension(L*W*H): | 2100x1300x2500(mm) |
| Power(W): | 3.5 kw |
| Model Number: | LC-PSM004 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Feature:
1. Adopt the anilox rollers to spread ink.
2. Unwinding and rewinding are controlled by magnetism power brake, clutch.
3. Printing unit adopt 360 for registration.
4. Each Printing unit has one infrared to dry the device group.
5. the rubber roller can break away from automatically while parking, and running at a low speed, in order to avoid water being dried.
6. the main motor is adopted the step less regulation of frequency conversion.
Main technical parameter:
Model |
SLT-RI480 |
SLT-RI650 |
Printing speed |
80m/min |
80m/min |
Printing color |
2colors |
2colors |
Max. Web width |
480mm |
650mm |
Max. Printing width |
460mm |
630mm |
Max. Unwinding diameter |
600mm |
1000mm |
Max. Rewinding diameter |
600mm |
1000mm |
Printing girth |
175-380mm |
175-380mm |
Precision of registration |
0.10mm |
0.10mm |
Dimensions |
2100x1300x2500(mm) |
4000x1600x2500(mm) |
Machine weight |
about 2600kg |
about 3500kg |
