| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 year |
| Voltage: | 380V,3P.50HZ |
| Brand Name: | Allfine |
| Condition: | New |
| Weight: | 2000kg |
| Dimension(L*W*H): | 2200x1800x1400mm |
| Power(W): | 6kw |
| Model Number: | LC-SRM001 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Use:
Machine in this series are mainly suitable for straw paper.
Feature:
1. the machine use center winding and the surface drum rewinding .
2. Web guide system, automatic tension control system with magnetic powder brake and clutch device
3. Machine with meter counter , automatic stop
4. Frequency Inverter control main motor
5. Optional: pneumatic loading unwinder, 3 Servo motor control rewinding system, Max rewinding diameter 800mm,Siemens PLC Touch Screen automatic tension control system
Main technical parameter:
Model |
SLT-SH700 |
SLT-SH900 |
Max. Width of roll material |
700mm |
900mm |
Max. Diameter of roll material |
1000mm |
1000mm |
Max. Diameter of rewinding roll |
600mm |
600mm |
Min. Width of slitting |
10mm |
10mm |
Slitting Speed |
0-200m/min |
0-200m/min |
Total Power |
6kw |
6kw |
Overall dimension ( L x W x H mm) |
2200x1800x1400 |
2200x2000x1400 |
Weight |
2000kg |
2200kg |
