| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | ALLFINE |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | CE |
| Weight: | 2.5Ton |
| Dimension(L*W*H): | 3000*2500*4200mm |
| Power(W): | 34kw |
| Voltage: | 380V |
| Model Number: | LC-40X2-700 |
| Place of Origin: | China (Mainland) |
| Application: | Film |
| Extrusion Output(Single):: | 45kg/h |
| Single-Sided Thickness Of Film:: | 0.01-0.10mm |
| Max Folding Width Of Film:: | 600mm |
| Range Of Die: | 100mm |
| Screw Speed: | 15-100r/min |
| Name:: | Rotary Die Head Film Blowing Machine For Polythene Polyethylene Plastic |
Quick Details
Specifications
Rotary Die Head Film Blowing Machine for Polythene Polyethylene Plastic
Hot Sale Rotary Die Head High Speed Polythene Polyethylene Plastic PE LDPE HDPE Film Blowing Machine Price
Film blowing machine, film blown machine, film machine,plastic film blowing machine, PE film blowing machine, blow film machine
Machine Introduction
1. Its extruder, cylinder and screw rods are made of quality alloy steel that have been notarized and processed in a precision way.
2. Hence it is hard, durable in corrosioN resistance. the specially-designed screw is quality in plasticizing, which helps increase the production capacity.
3. It is applied to blowing the plastic films like low density polygene (LDPE), high density polygene(HDPE) and linear low density polygene (LLDPE).
4. It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
Machine Advantages
1, We use stronger steel plate for machine body, which make machine more stable
2, Screw and barrel is nitrigened by 72 hours. 38 chromium materials, it is very hard. Copied from Taiwan
3, Hard surface gearbox, the life can be more 5 years.
4, Motor with CE standard, more 10 years life, fromGermany
5, Electric parts is CHINT, best supplier in China.
6, Easy to operate and one worker can run 3 sets
7, Temperautre Controller:from Japan
8, Inverter:from Korea
9, Ceramic Heater: Heating faster and Keep warm longer
Main Technical Variables:
| Model | LC-50-600 | LC-55-800 | LC-60-1000 | LC-65-1200 |
| Screw Diameter (mm) | 50 | 55 | 60 | 65 |
| Screw Length (L/D) | 28:1 | 28:1 | 28:1 | 28:1 |
| Film Width(mm) | 300-600 | 300-800 | 400-1000 | 600-1200 |
| Film Thickness(mm) | 0.008-0.10 | 0.008-0.10 | 0.008-0.10 | 0.008-0.10 |
| Max.Extrusion Output(kg/h) | 50 | 65 | 70 | 75 |
| Cylinder Cooling (Kw) | 0.25 | 0.25 | 0.25*2 | 0.25*2 |
| Driving Motor(kw) | 11 | 15 | 18.5 | 22 |
| Temperature Control | 3 | 3 | 3 | 4 |
| Average Power-consume(kw) | 14 | 22 | 26 | 37 |
| Die Size(mm) | 60/100 | 80/120 | 100/150 | 100/200 |
| Winding Speed(m/min) | 10-100 | 10-100 | 10-100 | 10-80 |
| Take-up Motor(kw) | 0.75 | 0.75 | 1.1 | 1.5 |
| Weight of machine(kg) | 2200 | 2600 | 3000 | 3300 |
| Cover Dimension(m) | 5.0*2.1*3.8 | 5.0*2.3*4 | 5.5*3.3*4.2 | 5.8*3.6*4.5 |
Work Shops
1.WORKERS ARE 10YEARS AVERAGE WORKING EXPERIENCE.
2.MAIN PARTS like DIE HEAD and SCREW and AIR RING, MACHINED IN CNC EQUIPMENT.
3. STRONG BODY WELDING FRAME and CAREFULLY PAINT.
4.GOOD BRAND USED, like SIEMENS, ABB, YASKAWA, DELTA, LS, OMRON, SCHNEIDER....
Packing & Delivery
WE WILL PAY ATTENTION to EVERY PARTS PACKING with BUBBLE FILM and STRETCH FILM or WOODEN CASE IF POSSIABLE. BESIDES, WE WILL LAOD MACHINES ONE by ONE CAREFULLY. and OUR DELIVERY TEAM IS PROFESSIONAL ON ALL the MACHINE INSPECTION and CERTIFICATES for YOUR CLEARANCE CUSTOM.
Our Service
ALLFINE BORN of GOOD SERVICE and MACHINE. WE HAVE OUR MACHINE ENGINEER TEAM and OVERSEAS SERVICE AVAILABLE.
WE ALSO HAVE PROFESSIONAL INSPECTION TEAM, GOOD SALES TEAM and after- SERVICE ONLINE 24 HOURS TEAM. OUR MACHINE IS QUALITY STRICKLY CONTROLLED.
WELCOME YOU to JOIN US!
HD Video link about LC-45 mini type film blowing machine
Https://youtu.Be/d1BY1mQprn0
HD Video link about LC-1500 PE film blowing machine extruder (1500mm width, export to Bangladesh)
Https://youtu.Be/ahjr26sz_aI
HD Video link about LC-50-700 film blowing machine
Https://youtu.Be/tiLDZY7ueWA
HD video link about ABA 2 layers Co-extrusion PE film blowing machine
Https://youtu.Be/OIS4b52QpuQ
