| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | ALLFINE |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | CE |
| Weight: | 2.5Ton |
| Dimension(L*W*H): | 3000*2500*4200mm |
| Power(W): | 34kw |
| Voltage: | 380V |
| Model Number: | LC-40X2-700 |
| Place of Origin: | China (Mainland) |
| Application: | Film |
| Extrusion Output(Single):: | 45kg/h |
| Single-Sided Thickness Of Film:: | 0.01-0.10mm |
| Max Folding Width Of Film:: | 600mm |
| Range Of Die: | 100mm |
| Screw Speed: | 15-100r/min |
| Name:: | HDPE LDPE Plastic Blown Film Machine 45mm Screw Diameter Improved Production Capacity |
Quick Details
Specifications
HDPE LDPE Plastic Blown Film Machine 45mm Screw Diameter Improved Production Capacity
HAS VIDEO Mini polyethylene HDPE LDPE plastic film blowing blown machine Price for Package Bag, Agriculture Cover
Film blowing machine, film blown machine, film machine,plastic film blowing machine, PE film blowing machine, blow film machine
Feature:
1. Mode LC45-600 squeezing machine is adopted fixed die head,machine tube is adopted 38CrMoAl,having the best hardness and corrosion-resisting performance after nitrogen treatment and precision processing.
2. LC45-600 auxiliary machine can adjust and operate freely within the range of 500mm in accordance with the technological demand of different materials, and having package board mechanism which can make vest type bag.
Product Application:
1. the specially-designed screw is quality in plasticizing, which helps increase the production capacity.
2. It is applied to blowing the plastic films like low density polygene (LDPE), high density polygene(HDPE) and linear low density polygene (LLDPE).
3. It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
Details |
. EXTRUSION UNIT:
1. Main motor: Power: 11kw Motor speed: 1470r/min
2. Gear box: High strength hard surface gear
3. Screw and barrel: Material: Alloyed high-quality Alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment. L/D ratio of screw: 30:1 Speed of screw: 15-120r/min
4. Die head: Type: Fixed die head Die dimension: 45 Air ring: cast aluminium air ring.
5. Heating zones: Screw heating area: 3 areas Heating loops: cast Aluminium Temperature digital controls
6. Film parameter: Max. Lay flat Width of film: 200-500mm Output capacity: 35kgs/h
|
. TAKE-up UNIT
1. Take up roller: Width:600mm Effective film width: 500mm
2. Take-up motor: Power: 0.75kw Frequency inverter control
3. Bubble stabilizer: squirrel cage
4. Take-up speed: 10-60M/minute
|
. WINDING UNIT
1. Working method: One station rewinding Friction tension control
2. Roller Width: 600mm Effective width: 500mm
3. Winding motor: Frequency inverter control Motor Winding speed: 10-60m/min
|
. CONTROL CABINET
1. Temperature controllers: Digital control, five sets.
2. Frequency inverter control panel
3. Independent switches controls including amp, rpm and m/min meters.
|
. MACHINE DIMENSION
1. Power supply: A/C 380v, 50Hz, 3-Phase
2. Machine weight (kg): 1.4T
3. External dimension (L*W*H): 2.2m*1.4m*2.2m
|
. SPARE PART
-Air compressor: 1set
-Temperature controller: 2pcs
-Amp meter 1pc -Voltage meter:1pcs
-Thermocouple: 1pcs
|
