| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | ALLFINE |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | CE |
| Weight: | 2.5Ton |
| Dimension(L*W*H): | 3000*2500*4200mm |
| Power(W): | 34kw |
| Voltage: | 380V |
| Model Number: | LC-40X2-700 |
| Place of Origin: | China (Mainland) |
| Application: | Film |
| Extrusion Output(Single):: | 45kg/h |
| Single-Sided Thickness Of Film:: | 0.01-0.10mm |
| Max Folding Width Of Film:: | 600mm |
| Range Of Die: | 100mm |
| Screw Speed: | 15-100r/min |
| Name:: | PE Biodegradable Film Blowing Machine Premium Quality In Width100 - 500mm |
Quick Details
Specifications
PE Biodegradable Film Blowing Machine Premium Quality In Width100 - 500mm
High Quality high speed PE Biodegradable Film Blowing Machine Extruder Plastic Machine in width100-500mm
Film blowing machine, film blown machine, film machine,plastic film blowing machine, PE film blowing machine, blow film machine
Use:
It applies to blow various LDPE, HDPE and LLDPE plastic films, widely applying to food, fruit, clothing, textile, vest type bag and etc. Packing of civil industrial products.
Product Application:
1. Its extruder, cylinder and screw rods are made of quality alloy steel that have been notarized and processed in a precision way.
2. Hence it is hard, durable in corrosion resistance. the specially-designed screw is quality in plasticizing, which helps increase the production capacity.
3. It is applied to blowing the plastic films like low density polygene (LDPE), high density polygene(HDPE) and linear low density polygene (LLDPE).
4. It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
Main technical parameters:
| Model | 45-600 |
| Screw Diameter | 45 |
| Screw Ratio L/D | 26:1 |
| Screw Speed | 15-120r/min |
| Main Motor Power | 11kw |
| Extrusion Output(Single) | 35kg/h |
| Range of Die | 50 100 |
| Single-Sided Thickness of Film | 0.005-0.10mm |
| Max Folding Width of Film | 100-500mm |
| Electric Total Capacity | 13kw |
| Overall Dimension | 220014002200mm |
| Weight of Machine | 2.0T |
Details |
. EXTRUSION UNIT:
1. Main motor: Power: 11kw Motor speed: 1470r/min
2. Gear box: High strength hard surface gear
3. Screw and barrel: Material: Alloyed high-quality Alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment. L/D ratio of screw: 30:1 Speed of screw: 15-120r/min
4. Die head: Type: Fixed die head Die dimension: 45 Air ring: cast aluminium air ring.
5. Heating zones: Screw heating area: 3 areas Heating loops: cast Aluminium Temperature digital controls
6. Film parameter: Max. Lay flat Width of film: 200-600mm Output capacity: 35kgs/h
|
