LCS-MT-L bulk bag filling machine is controlled by computerized instrument and easy to operate & manage. Lifting weighing system effectively protects itself from the damage by forklift. For example, filling bagging 1000kg jumbo bags, you just need to input it 1000kg as the target net weight and place the bag ready to the machine hanger, then the machine will automatic weighing filling 1000kg per bag, then, unloading the filled bag and the matching underling rolling conveyor will transport the filled bags outer or forklift carrying away.

Flowing Process:

Bag supplied & clamped by manual Automatic filling Automatic weighing Automatic bag conveyer(Optional

[Applicable bags]:Bulk bag, FIBC bag, jumbo bag, big bag with 4 loops, ton bag, super bag

[Solution for]:plastic granules, hpde pellet, cat litter, cat sand, urea fertilizer, potash fertilizer, gypsum powder, talc powder, calcium carbonate powder, cocoa power,etc.



Main Structure

1. Automatic filling and weighing system:

  1.1 Feeding/dosing system- belt type/screw/gravity-flow/vibration

  1.2 Weighing sensor

  1.3 Weighing balance

  1.4 Bag hanger and clamping system (pneumatic), automatic take-off bag loops

  1.5 Bag lifting system (pneumatic)

  1.6 Bag inflation system

  1.7 Automatic rolling conveyor (1.5meter+2.5meter, Optional)

2. Electric control cabinet



Technical Parameters

Type: LCS-MT-L

Precision: 0.2%FS

Weighing Scope: 100-500KG/500-1000KG/1000-2000KG

Production capacity: 10-15 bag/hour (depending on discharging temperature, air content, etc.)

Power Supply: 380V A.C. 50HZ/ Can be customized

Power: 4 (KW)

Compressed Air: 0.5~0.6(Mpa)

Compressed Air Consume: 0.6 (m3/h)



Typical Case
