| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | ALLFINE |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | CE |
| Weight: | 2.5Ton |
| Dimension(L*W*H): | 3000*2500*4200mm |
| Power(W): | 34kw |
| Voltage: | 380V |
| Model Number: | LC-40X2-700 |
| Place of Origin: | China (Mainland) |
| Application: | Film |
| Extrusion Output(Single):: | 45kg/h |
| Single-Sided Thickness Of Film:: | 0.01-0.10mm |
| Max Folding Width Of Film:: | 600mm |
| Range Of Die: | 100mm |
| Screw Speed: | 15-100r/min |
| Name:: | Compact Design Film Blowing Machine Extrusion Output 35 Kg/H With Fixed Die Head |
Quick Details
Specifications
Compact Design Film Blowing Machine Extrusion Output 35 Kg/H with Fixed Die Head
HD Video link about LC-45 mini type film blowing machine
Https://youtu.Be/d1BY1mQprn0
HD Video link about LC-1500 PE film blowing machine extruder (1500mm width, export to Bangladesh)
Https://youtu.Be/ahjr26sz_aI
HD Video link about LC-50-700 film blowing machine
Https://youtu.Be/tiLDZY7ueWA
HD video link about Film blowing machine and plastic bag making machine workshop of Ruian Allfine Machinery Co,Ltd
Https://youtu.Be/vy7t-u1LkaM
HD video link about LC-50-600 PE film blowing machine with heat slitting knife
Https://youtu.Be/uJLrLIeozoI
Hot Sale Rotary Die Head High Speed Polythene Polyethylene Plastic PE LDPE HDPE Film Blowing Machine Price
Film blowing machine, film blown machine, film machine,plastic film blowing machine, PE film blowing machine, blow film machine
LIFT TOWER MOVING up and DOWN TRACTION TYPE PE HDPE LDPE MINI FILM BLOWING MACHINE SHORT IN HEIGHT
Feature:
1. Model LC45-600 squeezing machine is adopted fixed die head,machine tube is adopted 38CrMoAl,having the best hardness and corrosion-resisting performance after nitrogen treatment and precision processing.
2. LC45-600 auxiliary machine can adjust and operate freely within the range of 500mm in accordance with the technological demand of different materials, and having package board mechanism which can make vest type bag.
Product Application:
1. the specially-designed screw is quality in plasticizing, which helps increase the production capacity.
2. It is applied to blowing the plastic films like low density polygene (LDPE), high density polygene(HDPE) and linear low density polygene (LLDPE).
3. It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
Main technical parameters:
| Model | 45 |
| Diameter of Screw(mm) | 45 |
| Max. Width of Folded Film (mm) | 100-500 |
| Single-face Thickness of Film(mm) | 0.01-0.10 |
| Max. Extrusion(kg/h) | 35 |
| L/D | 26:1 |
| Power of Main Motor(KW) | 7.5-11 |
| Power of Traction Motor(KW) | 1.1 |
| Heating Power(KW) | 11 |
| Overall Dimension (mm) | 3800*1900*3000 |
| Weight(T) | 1.5T |
Film blowing machine, film blown machine, film machine,plastic film blowing machine, PE film blowing machine, blow film machine
|
. EXTRUSION UNIT: Power: 11kw Motor speed: 1470r/min High strength hard surface gear Material: Alloyed high-quality Alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment. L/D ratio of screw: 26:1 Speed of screw: 15-120r/min Type: Fixed die head Die dimension: 45 Air ring: cast aluminium air ring. Screw heating area: 3 areas Heating loops: cast Aluminium Temperature digital controls Max. Lay flat Width of film: 200-600mm Output capacity: 35kgs/h |
. TAKE-up UNIT Effective film width: 600mm Power: 0.75kw Frequency inverter control |
. WINDING UNIT Winding speed: 10-60m/min |
Configuration:
| Temperature meter | Omron |
| Switch | Schneider |
| Inverter | Delta |
| Relay | Omron |
| Solenoid valve | Taiwan |
| Thermocouple | RKC JAPAN |
| Voltmeter | Japan |
| Ammeter | Japan |
| Barrel and screw material | 38 chrome-molybdenum aluminum, nitrogen treated |
| Gear box | Hard tooth surface |
| Head | Rotary die head |
| Winder | Double rewinder |
| Main motor | CHINESE BRAND |
| Heating ring | Cast aluminum |
| Winder motor | Torque motor |
| Embossing roller | yes |
| Power | 3PASE 380V 50HZ |
