| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | ALLFINE |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | CE |
| Weight: | 2.5Ton |
| Dimension(L*W*H): | 3000*2500*4200mm |
| Power(W): | 34kw |
| Voltage: | 380V |
| Model Number: | LC-40X2-700 |
| Place of Origin: | China (Mainland) |
| Application: | Film |
| Extrusion Output(Single):: | 45kg/h |
| Single-Sided Thickness Of Film:: | 0.01-0.10mm |
| Max Folding Width Of Film:: | 600mm |
| Range Of Die: | 100mm |
| Screw Speed: | 15-100r/min |
| Name:: | PE Mini Film Blowing Machine Integral Type 11KW Heating Power With Single Winder |
Quick Details
Specifications
PE Mini Film Blowing Machine Integral Type 11KW Heating Power with Single Winder
HD Video link about LC-45 mini type film blowing machine
Https://youtu.Be/d1BY1mQprn0
HD Video link about LC-1500 PE film blowing machine extruder (1500mm width, export to Bangladesh)
Https://youtu.Be/ahjr26sz_aI
HD Video link about LC-50-700 film blowing machine
Https://youtu.Be/tiLDZY7ueWA
HD video link about Film blowing machine and plastic bag making machine workshop of Ruian Allfine Machinery Co,Ltd
Https://youtu.Be/vy7t-u1LkaM
HD video link about LC-50-600 PE film blowing machine with heat slitting knife
Https://youtu.Be/uJLrLIeozoI
Hot Sale Rotary Die Head High Speed Polythene Polyethylene Plastic PE LDPE HDPE Film Blowing Machine Price
Film blowing machine, film blown machine, film machine,plastic film blowing machine, PE film blowing machine, blow film machine
PE mini Plastic Film Extrusion Machine with Integral type & single winder for HDPE/ldpe/lldpe
Use:
1. Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way.
2. Hence it is sound in hardness, durable in corrosion resistance. the specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity.
3. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE).
4. Is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
OPTIONAL EQUIPMENT:
1) AUTO LOAD
2) AIR COMPRESSOR
3) SPECIAL DIE
4) DIE ROTARY DEVICE
5) BOUBLE SIDES WINDER
6) up and DOWN
Main Technical Variables:
| Model | A50 | A55 | A65 | A65-1 |
| Diameter of screw | 50 | 55 | 65 | 65 |
| Rcduced diameter of film(mm) | 100-600 | 200-800 | 300-1000 | 400-1200 |
| Single-face Thickness of film(mm) | 0.01-0.10 | 0.01-0.10 | 0.01-0.10 | 0.01-0.10 |
| Max.Extrusion(Kg/h) | 35 | 50 | 65 | 80 |
| L/D | 28:1 | 28:1 | 28:1 | 28:1 |
| Power of main moto(kw) | 11 | 15 | 18.5 | 22 |
| Power of Tracion main moto(kw) | 0.75 | 1.1 | 1.5 | 1.5 |
| Heating Power(kw) | 15 | 18 | 23 | 27 |
| Outline diameter(L x W x H) (mm) | 4800 x 1900 x 4100 | 5500 x 2100 x 4700 | 6500 x 2300 x 4900 | 6500 x 2500 x 5600 |
| Weight(T) | 1.5T | 2T | 2.3T | 2.6T |
FAQ:
Q1: how to visit our Factory? (not a trade company)
A: Option 1: Guangzhou Airport Wenzhou Airport Pick you up Option 2: Shanghai Airport Wenzhou Airport or Rui'an Train StationPick you up
Q2: how does your factory do the quality control?
A:" QUALITY FIRST " We purchase qualified parts, test the machine every step when manufacturing.
Q3: how about the installation?
A: Option 1, our engineer install the machines for you, also train your staff until they can run the machine independently. Option 2, you learn installation in our factory.
Q4:Do you have after-sale service?
A: 1 Year Warranty and timeless maintenance service. Service center in Pakistan, Russia.
Q5: how about the payment term?
A: Payment term:1, T/T 30%, 70% before shipping. 2, Ali Secure Payment.
