| Model |
HQ-0540 |
HQ-1040 |
HQ-2540 |
HQ-5040 |
HQ-0575W |
HQ-1075W |
HQ-2575W |
HQ-5075W |
| Gas flow |
5m3/h |
10m3/h |
25m3/h |
50m3/h |
5m3/h |
10m3/h |
25m3/h |
50m3/h |
| Lowest Temp. |
-40 |
-40 |
-40 |
-40 |
-75 |
-75 |
-75 |
-75 |
| Primary Temp. |
There is no |
-20 |
-20 |
-20 |
-20 |
| Cold box under pressure |
025bar |
025bar |
025bar |
025bar |
025bar |
025bar |
025bar |
025bar |
| Heat Transfer Area |
0.8m2 |
1.5m2 |
3m2 |
5m2 |
0.8m2*2 |
1.5m2*2 |
3m2*2 |
5m2*2 |
| Heat Exchanger Material |
the standard configuration is copper tube, which can be selected with SUS304\SUS316L. |
| Low temp. refrigerating capacity |
0.8kw |
1.5kw |
3kw |
5kw |
0.8kw |
1.5kw |
3kw |
5kw |
| Cooling way |
Air cooling |
Water cooled |
| Air inlet orifice |
M16*1 |
M24*1.5 |
M38*1.5 |
DN50 |
M16*1 |
M24*1.5 |
M38*1.5 |
DN50 PN25 |
| Recovery tank |
2L |
3L |
10L |
15L |
2L |
3L |
10L |
15L |
| Discharge orifice |
M16*1 |
M24*1.5 |
M24*1.5 |
M24*1.5 |
M16*1 |
M24*1.5 |
M24*1.5 |
M24*1.5 |
| Control system |
Siemens S7 series PLC and module. |
| Display-record |
7 inch color touch screen, record curve temperature and alarm. |
| the compressor |
the French taikang/Emerson valley wheel/Italy is a compressor. |
| the power supply |
220V 50HZ |
220V 50HZ |
380V 50HZ |
380V 50HZ |
220V 50HZ |
220V 50HZ |
380V 50HZ |
380V 50HZ |
|
|
1.2KW |
1.8KW |
3.5KW |
6.6KW |
2KW |
2.5KW |
6KW |
10KW |
