| Brand Name: | OF |
|---|---|
| Wavelength: | 1550nm |
| Data Rate: | 10G |
| warranty: | 1year |
| Connector: | FC/APC |
| Place of Origin: | China (Mainland) |
| PM1550: | PM1310 |
Quick Details
Specifications
Polarization Maintaining Fiber Patchcord/Connector |
Product Features |
|
Product Applications |
|
Specifications | |||
Parameter |
Unit |
Value | |
Center Wavelength (c) |
nm |
980,1064,1310 or 1550 | |
Connector Type |
- |
UPC |
APC |
Typ. Insertion Loss |
dB |
0.3 |
0.4 |
Max. Insertion Loss |
dB |
0.5 | |
Min. Return Loss |
dB |
50 |
60 |
Min. Extinction Ratio |
dB |
24 | |
Max. Optical Power (Continuous Wave) |
mW |
300 | |
Fiber Length Tolerance |
% |
10 or specify | |
Tensile Load |
N |
5 | |
Fiber type |
- |
PM980,PM1550,or other PM panda fiber | |
Operating Temperature |
-5 to +70 | ||
Storage Temperature |
-40 to +85 | ||
*IL is 0.1 DB higher for 980 & 1060 nm. Connector key is aligned to slow axis.
Ordering Information | |||||
PMP |
Wavelength |
Pigtail Type |
FiberType |
Length |
Connector |
|
980nm 1060nm 1310nm 1480nm 1550nm Specify |
250um bare fiber 900um loose tube 2mm cable 3mm cable Specify |
PM panda fiber Specify |
0.5m 1m 1.5m 2m Specify |
FC/APC SC/UPC LC/UPC Specify |
