| Weight: | 620 |
|---|---|
| Brand Name: | sanxing feirong |
| CNC or Not: | Normal |
| Type: | Internal Grinding Machine |
| Condition: | New |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Dimension(L*W*H): | 1140*895*1825 |
| Power(W): | 7500 |
| Voltage: | 380 |
| Model Number: | SP-1.5L |
| Place of Origin: | China (Mainland) |
| Max. Grinding Diameter: | micro size |
| rotator structure: | turbine-agitator with pins |
| barrel component: | alloy steel, PU, ceramic |
| grinding fineness: | micron, sub-micron, nano-meter |
| grinding media size: | 0.05-2mm |
Quick Details
Specifications
Features:
1 Rotator structure: Turbine-agitator with pins
2 Barrel component: alloy steel, PU or ceramic
3 : Micron-, submicron-, nano-meter
4 No mechanical sealing, and easy installation and maintenance
5 No separation screen mesh without clogging and cleaning
6 Grinding media size: 0.05-2.0mm
7 Efficient ultrafine classification and grinding
in grinding process, fine particles are classified from grinding barrel, thus avoiding over-grinding, while coarse particles are ground, resulting in the efficient production of fine particles, due to the centrifugal separation in the mill. As a result, final product with narrow particle size distribution is obtained.
Model
|
Volume (L) |
Power (kW) |
Rotational speed (rpm) |
Flow rate (L/h) |
BEad diameter (mm) |
BEad loading (Vol. %) |
Size (mm) |
Weight (kg) |
SP-0.5 |
0.5 |
3.7 |
1450 |
20-40 |
0.05-2.0 |
65-80 |
L675W880H1257 |
235 |
SP-1.5 |
1.5 |
7.5 |
1450 |
80-100 |
0.05-2.0 |
65-80 |
L1140W895H1825 |
620 |
SP-5 |
5 |
18.5 |
1450 |
200-300 |
0.05-2.0 |
65-80 |
L1280W1090H1700 |
1230 |
SP-15 |
15 |
37 |
1450 |
400-600 |
0.05-2.0 |
65-80 |
L1520W1150H2050 |
1800 |
SP-30 |
30 |
55 |
1480 |
600-1000 |
0.05-2.0 |
65-80 |
L1765W1220H2250 |
2300 |
SP-60 |
60 |
75 |
960 |
1200-2000 |
0.05-2.0 |
65-80 |
L2140W1640H2420 |
4900 |
SP-100 |
100 |
132 |
960 |
2500-5000 |
0.05-2.0 |
65-80 |
L2260W1690H2590 |
5100 |
