| Brand Name: | sighton |
|---|---|
| Combination: | rf modulator |
| Warranty: | 3years |
| Interface Type: | 16 ASI input,4 ASI |
| Frequency: | 30 to 960MHz,1kHz stepping |
| Model Number: | STM-2400 |
| Place of Origin: | China (Mainland) |
| Input: | 16 channels ASI input 4 channels ASI input 8 DVB-S2 tuner input |
| Input Channel: | 16 channels ASI input 4 channels ASI input 8 DVB-S2 tuner input |
Quick Details
Specifications
Key Features
*Support 16 ASI input, 4 ASI input, 8 DVB-S2 tuner input Optional
* Fully support DVB-C (EN300 429) and ITU-T J.83A/B/C
*Fully support DVB general scrambling system description ETR289, Simulcrypt standard ETSI 101 197 and ETSI 103 197
*Support 4 channels multiplexing, 4 channels scrambling and 4 channels QAM modulating
*Support gigabit IP output
*Simultaneously support 4 simulcrypt CA
*Support accurate PCR adjusting
*Support PSI/SI editing and inserting
*Excellent RF output performance index, MER40db
*Support LCD display and keyboard
*Support SNMP management
Principle Chart
Specifications
Input |
16 Channels ASI input |
STM-2400-16 | ||
4 channels ASI input |
STM-2400-4 | |||
8 DVB-S2 tuner Input |
STM-2400-8 | |||
Multiplexing |
Input Channel |
16 Channels ASI input |
STM-2400-16 | |
4 Channels ASI input |
STM-2400-4 | |||
8 DVB-S2 tuner input |
STM-2400-8 | |||
Output Channel |
4 RF output, gigabit IP output | |||
Maximum PID Remapping |
256 Per input channel | |||
Function |
PID Remapping(automatically or manually) | |||
Accurate PCR adjusting | ||||
Generate PSI/SI table Automatically | ||||
Scrambling |
Maximum Simulcrypt CA |
4 | ||
Standard |
ETSI 101 197, ETSI 103 197 | |||
Connection |
Local/remote Connection | |||
Modulation |
QAM Channel |
4 | ||
Standard |
EN300 429/ITU-T J.83A/B/C | |||
Symbol Rate |
2.5Msps~4.66Msps, 5.0Msps~8.0Msps,1ksps stepping | |||
Constellation |
16,32,64,128,256QAM | |||
FEC |
RS(204, 188) | |||
RF Output |
Connector |
F Type, 75 impedance | ||
RF Range |
30~960MHz,1kHz stepping | |||
Output Attenuation |
-16dBm~-0dBm(per QAM carrier), 0.5dB Stepping | |||
MER |
40db | |||
ACLR(Adjacent Channel leakage ratio) |
-55dBC | |||
System |
Support LCD display, keyboard operation, and NMS/SNMP operation. English and Chinese Operation interface conversion | |||
Support Software Upgrading through Ethernet | ||||
General |
Dimension(W*D*H) |
482mm455mm44.5mm | ||
Weight |
3.7kg | |||
Temperature |
0~45(Operation) ; -20~80(Storage) | |||
Power |
AC100V1050/60HzorAC 220V10%,50/60HZ | |||
Consumption |
25W | |||
