| Brand Name: | sighton |
|---|---|
| Combination: | reference munal |
| Warranty: | 3years |
| Interface Type: | reference munal |
| Frequency: | reference munal |
Quick Details
Specifications
Features
* 3 GE ports (max 192 IP in):
Data1 & Data2 bi-directional ports, max 192 IP in, 6 IP out
Data port (located on front panel), max 128 IP in
* Max 840Mbps for each GE input
* Supports accurate PCR adjusting
* Supports CA filtering, PID remapping and PSI/SI editing
* Supports up to 180 PIDS remapping per channel
* Support 6 IP output through Data1 & Data2 over UDP/RTP/RTSP
* 6 non-adjacent carriers output, compliant to ISDB-Tb (ARIB STD-B31)
* Support Web-based Network management
Technical Parameter
Input |
Input |
Max 192 IP input through 3 (front-panel Data port, Data 1 and Data 2) 100/1000M Ethernet Port (SFP interface Optional). Each Data1 or Data 2 port can input max 192 IP, while Front-panel Data port can input max 128 IP |
Transport Protocol |
TS over UDP/RTP, unicast and multicast, IGMP V2/V3 | |
Transmission Rate |
Max 840Mbps for each GE input | |
Mux |
Input Channel |
192 |
Output Channel |
6 | |
Max PIDs |
180 per channel | |
Functions |
PID remapping (auto/manually optional) | |
PCR accurate adjusting | ||
PSI/SI table automatically generating | ||
Modulation Parameters |
Standard |
ARIB STD-B31 |
Bandwidth |
6M | |
Constellation |
QPSK, 16QAM, 64QAM | |
Guard Interval |
1/32, 1/16, 1/8, 1/4 | |
Transmission Mode |
2K, 4K, 8K | |
Code rate |
1/2, 2/3, 3/4, 5/6, 7/8 | |
MER |
40dB | |
RF frequency |
50~960MHz, 1KHz step | |
RF output level |
-20dBm~+10dBm(87~117dbV), 0.1dB stepping | |
RF Output |
Interface |
1 F typed output Port for 6 carriers, 75 impedance |
ACLR |
-50 dBc | |
TS output |
6 IP output over UDP/RTP/RTSP, Unicast/multicast, 2 (Data1& Data2) 100/1000M Ethernet Ports | |
System |
Network management software (NMS) Supporting | |
General |
Demission |
420mm440mm44.5mm (WxLxH) |
Weight |
3kg | |
Temperature |
0~45(operation), -20~80(storage) | |
Power Supply |
AC 100V10%, 50/60Hz or AC 220V10%, 50/60Hz | |
Consumption |
15.4W | |
