| Max. Reverse Current: | 1uA |
|---|---|
| Max. Reverse Voltage: | 5V |
| Package Type: | Through Hole |
| Type: | LED |
| Brand Name: | unionlight |
| Max. Forward Current: | 20MA |
| Max. Forward Voltage: | 2.2V |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
the following example is for you reference.
Features:
High brightness, stable, energy saving, low heat, low power consumption,long life span
Technical details:
Red: 1.8-2.2v, 20MA,5000mcd, 620-624nm, viewing angle:30
Yellow: 1.8-2.2v, 20MA,5000mcd,590-593nm, viewing angle:30
Green: 2.8-3.2v, 20MA,12000mcd, 502-505nm, viewing angle:30
Blue: 1.8-2.2v, 20MA,3000mcd,467-471nm, viewing angle:30
White 2.7-3.1v, 20MA,10000mcd, viewing angle:30
Operation method of useage:
Package:
