Features:

• Interchangeable manifolds for 8- and 12-well strips
• One or more strips of ELISA Plate washing keyboard choice directly
• Minimal residual volume (<1L/well)
• Dispense precision Cv<2%
• Detachable ELISA Plate pallet, convenient for the pallet clearing and sterilization
• Cleaning head 5-locations location adjusted,
• Shaking or soak time programmed.
• Automatic waste and lotion and distilled water liquid warning

Specification

Micro-plate Types:        48 / 96-well U-/V- / Flat-bottom plates or strips

Residual Volume:          1l / well typical

Dispense volume:        50l-950l, adjustable

Dispense precision:      CV < 2%

Washing Cycles:         1-99, optional

 Washing Mode:         1-12, rows and ranks selectable

Aspirate time:           0.5-9.5s

Soaking Time:           0-999s, adjustable

Shaking Time:           0-999s, adjustable

Display:                 Large LCD

Channel:                2 channels for washing liquid, 1 channel for waste liquid

Memory:                up to 100 programs can be stored

Interface:                RS232

Power Supply:           220\110VAC 10%, 50\60Hz

Temperature:            5-30 wet90%

Dimension:              430mm (L) 380mm (W) 120mm (H)

Net Weight:              12kg
