| Brand Name: | ADRA |
|---|---|
| Wavelength: | 1310nm |
| Data Rate: | 1.25Gbps |
| warranty: | 1Year |
| Connector: | LC |
| Model Number: | AR-3112-10 |
| Place of Origin: | China (Mainland) |
| Distance: | 10KM |
| DDMI: | Yes |
| Temp.: | 0~70 |
Quick Details
Specifications
Features
Dual data-rate of 1.25Gbps/1.063Gbps operation
1310nm FP laser and PIN photo detector for 10/20km transmission
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital Diagnostic Monitoring:Internal Calibration or External Calibration
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
Standard: 0 to +70C
Industrial : -40 to +85C
Applications
Gigabit Ethernet/Fiber Channel
Switch to Switch interface
Switched backplane applications
Router/Server interface
Other optical transmission systems
Ordering information
Part Number |
Description |
AR-3112-10 |
SFP1.25Gbps 1310nm 10KM DOM LC Connector,0~+70C |
AR-3112-10 |
SFP1.25Gbps 1310nm 10KM DOM LC Connector,-40~+85C |
AR-3112-20 |
SFP1.25Gbps 1310nm 20KM DOM LC Connector,0~+70C |
AR-3112-20 |
SFP1.25Gbps 1310nm 20KM DOM LC Connector,-40~+85C |
