| Brand Name: | ADRA |
|---|---|
| Wavelength: | 850nm |
| Data Rate: | 1.25Gbps |
| warranty: | 1Year |
| Connector: | LC |
| Model Number: | AR-8512-01 |
| Place of Origin: | China (Mainland) |
| Distance: | 550M |
| DDMI: | Yes |
| Temp.: | 0~70 |
Quick Details
Specifications
Features
Dual data-rate of 1.25Gbps/1.063Gbps operation
850nm VCSEL laser and PIN photo detector 550m transmission
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital Diagnostic Monitoring:Internal Calibration or External Calibration
500m transmission with 50/125m MMF
300m transmission with 62.5/125m MMF
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
Standard: 0 to +70C
Industrial : -40 to +85C
Applications
Gigabit Ethernet/Fiber Channel
Switch to Switch interface
Switched backplane applications
Router/Server interface
Other optical transmission systems
Ordering information
Part Number |
Description |
AR-8512-01 |
SFP1.25Gbps 850nm 550M DOM LC Connector,0~+70C |
AR-8512-01E |
SFP1.25Gbps 850nm 550M DOM LC Connector,-40~+85C |
