Quick Details
Specifications
the following example is for you reference.
Features:
First, the melting furnace type:
the melting furnace is a power-saving product, advanced technology, precise and reliable control, mature manufacturing process, safe and stable operation, perfect protection system, reasonable layout, convenient management and maintenance. It has the characteristics of fast melting speed , low energy consumption and stable and reliable operation.
Second, the Melting furnace Composition range:
Medium frequency power supply capacitor cabinet furnace body (steel shell or aluminum shell furnace body) tilting furnace system remote control box closed loop cooling tower
the melting furnace has protection systems such as overvoltage, overcurrent, water temperature, water pressure, short circuit, grounding, etc. the operation panel has various parameters of the working parameter display screen and the display working state, and there are indications such as fault and temperature.
Third, 0.25T melting furnace Technical Parameters
Power supply |
Working form: Single power supply 6 pulses |
Rectified form: 3- phase 6- pulse | |
Output power: 20 0KW or 300 KW , Different power prices. | |
Power efficiency 98% | |
Start mode: Sweep soft start | |
Startup rate: 100% (including heavy load) | |
Rated frequency: 500KHZ-1000KHZ | |
AC voltage: 400 V | |
DC voltage: 500 V | |
IF voltage: 750V | |
DC current: 600A | |
Input frequency: 50Hz | |
Circulating water volume: Closed loop Water cooling tower ZXZ-25T | |
Furnace body |
Rated capacity: 250 KG |
Maximum capacity: 3 00KG | |
Power factor: 0.9 2 | |
Melting time: about 50 min / oven | |
Working temperature: 155 0C -170 0C | |
Loading diameter: 220 Mm (upper mouth) Inner diameter of the ring: 420mm copper ring of the furnace is 20x25x3mm | |
Steel: Turndown maximum angle: 95 Aluminum Shell: turndown maximum angle: 180 | |
Outlet mode: side outlet or rear outlet | |
Circulating water volume: Closed loop water cooling tower ZXZ-25T | |
Tilting method: Aluminum shell 531 reducer, steel shell Hydraulic | |
Unit power consumption: 700 Degrees / T 5% 1550 C | |
Transformer |
Rated capacity: 315 KVA |
Primary voltage: 10KV | |
Secondary voltage: 400 V | |
One phase: 3 phase | |
Secondary phase number: /3 phase 6 pulse | |
Output form: three three Y | |
Cooling water System |
Closed - loop Water cooling tower ZXZ-25T |
Cooling capacity : 100000 kcal/h Cooling water volume : 25m3/h Fan power : 0.75 KW 2 units Fan air volume120 00m3/h 2 Spray pump 25 m3/h; 1.5 kw Dimensions mm 235 0 10 001950 (one size) |
Fourth , the Melting furnace Configuration table
Serial number |
Name |
Quantity |
Remarks |
1 |
IF power cabinet |
1 set |
|
2 |
Furnace body |
1 set |
Steel shell, yoke, |
3 |
Hydraulic system or reducer |
1 set |
Hydraulic power station |
4 |
External console |
1 set |
External control power adjustment for Tilting furnace |
5 |
Water cooled cable |
1 set |
2 roots |
6 |
Model |
1 |
3 Mm steel plate |
7 |
Rectifier transformer |
1 set |
Optional |
8 |
PLC automatic control display system |
1 set |
Optional |
9 |
Closed loop cooling tower |
1 set |
Optional |
10 |
Rectifier thyristor |
2 |
spare |
11 |
Inverter thyristor |
2 |
spare |
