| Brand Name: | ADRA |
|---|---|
| Wavelength: | TX1310/RX1550nm |
| Data Rate: | 1.25Gbps |
| warranty: | 1Year |
| Connector: | LC |
| Model Number: | AR-3512-10 |
| Place of Origin: | China (Mainland) |
| Distance: | 10KM |
| DDMI: | Yes |
| Temp.: | 0~70 |
Quick Details
Specifications
Features
100Mb/s to 1.25Gb/s bi-directional data links
A:1310nm FP laser and PIN photo detector for 10/20km transmission
B:1550nm DFB laser and PIN photo detector for 10/20km transmission
Compliant with SFP MSA and SFF-8472 with simplex LC or SC receptacle
Digital Diagnostic Monitoring:Internal Calibration or External Calibration
+3.3V single power supply
Operating case temperature:
Standard: 0 to +70C
Industrial: -40 to +85C
Applications
Gigabit Ethernet/Fiber Channel
Switch to Switch interface
Other optical links
Ordering information
Part Number |
Description |
AR-3512-10 |
SFP1.25Gbps Tx1310/Rx1550nm 10KM DOM LC Connector, 0~+70C |
AR-5312-10 |
SFP1.25Gbps Tx1550/Rx1310nm 10KM DOM LC Connector, 0~+70C |
AR-3512-10S |
SFP1.25Gbps Tx1310/Rx1550nm 10KM DOM SC Connector, 0~+70C |
AR-5312-10S |
SFP1.25Gbps Tx1550/Rx1310nm 10KM DOM SC Connector, 0~+70C |
AR-3512-10E |
SFP1.25Gbps Tx1310/Rx1550nm 10KM DOM LC Connector, -40~+85C |
AR-5312-10E |
SFP1.25Gbps Tx1550/Rx1310nm 10KM DOM LC Connector, -40~+85C |
AR-3512-10SE |
SFP1.25Gbps Tx1310/Rx1550nm 10KM DOM SC Connector, -40~+85C |
AR-5312-10SE |
SFP1.25Gbps Tx1550/Rx1310nm 10KM DOM SC Connector, -40~+85C |
AR-3512-20 |
SFP1.25Gbps Tx1310/Rx1550nm 20KM DOM LC Connector, 0~+70C |
AR-5312-20 |
SFP1.25Gbps Tx1550/Rx1310nm 20KM DOM LC Connector, 0~+70C |
AR-3512-20S |
SFP1.25Gbps Tx1310/Rx1550nm 20KM DOM SC Connector, 0~+70C |
AR-5312-20S |
SFP1.25Gbps Tx1550/Rx1310nm 20KM DOM SC Connector, 0~+70C |
AR-3512-20E |
SFP1.25Gbps Tx1310/Rx1550nm 20KM DOM LC Connector, -40~+85C |
AR-5312-20E |
SFP1.25Gbps Tx1550/Rx1310nm 20KM DOM LC Connector, -40~+85C |
AR-3512-20SE |
SFP1.25Gbps Tx1310/Rx1550nm 20KM DOM SC Connector, -40~+85C |
AR-5312-20SE |
SFP1.25Gbps Tx1550/Rx1310nm 20KM DOM SC Connector, -40~+85C |
