| Brand Name: | ADRA |
|---|---|
| Wavelength: | 1470~1610nm |
| Data Rate: | 10Gbps |
| warranty: | 1Year |
| Connector: | LC |
| Model Number: | ARX-Cxx96-ER |
| Place of Origin: | China (Mainland) |
| Distance: | 40KM |
| DDMI: | Yes |
| Temp.: | 0~70 |
Quick Details
Specifications
Features
Supports 9.95Gbps to 11.1Gbps bit rates
Uncooled CWDM EML laser and a receiver with a PIN photodiode
XFP MSA Rev 4.5 Compliant
Maximum link length of 40km with SMF
No reference clock required
+3.3V Supply Voltage
Low Power Dissipation 3.5W Maximum
XFI and lineside loopback Mode Supported
Operating case temperature: 0 to 70C
Applications
SDH STM I-64.1 at 9.953Gbps
10GBASE-ER/EW 10G Ethernet
10G Fiber Channel
Ordering information
Part Number |
Description |
ARX-Cxx96-ER |
CWDM XFP10Gbps 40KM LC Connector,0~+70C,xx=1470~1610nm |
