| Feature: | Other |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | CE/ISO9001 |
| Brand Name: | Maxtech |
| Condition: | New |
| Feature: | other |
| Warranty: | 12 months |
| Model Number: | Hydraulic Ship Marine Offshore Deck Cranes |
| Place of Origin: | China (Mainland) |
| Span: | 3-30m |
| Max. Lifting Height: | 35m |
| Max. Lifting Load: | 30ton |
| Rated Lifting Moment: | limiter |
| Rated Loading Capacity: | 3t |
| Application: | Construction, Offshore |
| Color: | Customized Color Acceptable |
Quick Details
Specifications
HOISTING SPEED: 0~15m/min
SLEWING SPEED: ~0.6r/min
SLEWING ANGLE: 360
LUFFING TIME: ~90s
ELEC-MOTOR POWER: Y160L-4-H
POWER: 90kw
POWER RESOURCE: AC440V/60HZ
PROTECT CLASS: IP44
INSUKATE CLASS: F
- SWL: 3T@30M&30T@6M
Max. Working radius: 30m
Min. Working radius: 3m
Hoisting speed: 0-15m/min
Hoisting height: 35m
Rotalon angle: 360
Slewing speed: 0.6r/min
Luffing time: 90s
Power: 90kw
- the Maxtech Shanghai Corporation provides high
Quality handling solutions and access systems for the marine, offshore, port
Industries. Headquartered in beautiful Shanghai, China, Maxtech Shanghai Corporation
Has subsidiaries in several countries and serves a global client base from
Strategic points in Europe, Asia, Africa, Australia and Middle East.
with years of experience, the Maxtech Marine Group Has its own designing team and manufacturing factory, excellent European Management who has 40 years of experience on offshore business, which also Provides after sales services overseas.
Our production line covers marine and offshore Knuckle boom crane, telescopic crane, stiff boom crane, non-standard steel Structure, more environmental-friendly operations and also truck crane with the Range from 15t to 150t.Port industry which includes cranes, hoppers and grabs.
Maxtech Machinery can build any type of handling Equipment, according to our own design, but also according to provided designs.
We build products according to any certification Requested by the client and are able to build them for working in, and under Extreme heavy circumstances for working tempertures of - 40C accordingly.
