Product Main

Quick Details

Brand Name:	TreLink
Input connector type:	N Female
Lightning protection:	DC Ground
Gain(dBi):	11
Frequency range(MHz):	698-2700 MHz
Model Number:	TLYD-627-11V
Place of Origin:	China (Mainland)

Specifications

Electrical Specifications
Model	TLYD-627-11V
Frequency Range	698-960 MHz	1710-2700MHz
Gain	9.5+/-1dBi	10+/-1dBi
VSWR	1.8: 1
Polarization	Vertical
Front to Back Ratio	16dB
Horizontal Beamwidth	65	50
Vertical Beamwidth	50	40
Input Impedance	50
Maximum Power	100 W
Lightning Protection	DC Ground
Mechanical Specifications
Connector	N female
Antenna Dimension	430*210*80 mm
Weight	1 kg /2.2 lb
Radome Material	Weatherproof ABS
Mounting method	Fit with nut
Wind Velocity	210 km/h
Working Temperature	-40~+60
