| Brand Name: | TreLink |
|---|---|
| Input connector type: | N Female |
| Lightning protection: | DC Ground |
| Gain(dBi): | 12 |
| Frequency range(MHz): | 2400-2500 |
| Model Number: | TLOD-2400-12V |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
| Electrical Specifications | |
| Model | TLOD-2400-12V |
| Frequency Range | 2400-2500 MHz |
| Gain | 12 dBi |
| VSWR | <1.5:1 |
| Polarization | Vertical |
| Horizontal Beamwidth | 360 |
| Vertical Beamwidth | 7 |
| Input Impedance | 50 |
| Maximum Power | 100W |
| Lightning Protection | DC Ground |
| Mechanical Specifications | |
| Connector | N Female |
| Antenna Dimension(diameter*length) | 25*940 mm |
| Weight | 1.8 kg /3.9 lb |
| Radome Material | Fiberglass |
| Wind Velocity | 210 km/h |
| Working Temperature | -40~+65 |
| Mounting Pole | 40-60 mm |
