Name:T handle quick release pin, ball lock pin
P/N:M10ST50

Specs: Diameter 10mm  Grip length 50mm

Material:
Body          SS304
Button       HPb59-1
Spring       SS304
Handle      ADC10.1
Ring          SS304
Balls         440C

Quick release pin,ball lock pin,detent pin,self lock pin,positive lock pin of RITEON Is used for all kinds of quick dismantling & fitting while needing to repeat positioning accuracy.

Features:
1. It can be auto defense and make the ball of the pin head be retractable by pressing the button of the handle, at this time you can let the Quick release pin Be passed through the pin hole quickly;
2. When you release the button, the ball will be poped up, quick release pin will can't be pulled out;
3. High precision, the tolerance of diameter and grip length are very strict;
4. the coverage of application is wide, according to the environment you can choose to use high-strength alloy steel and stainless steel material;
5. According to the space conditions of handle you can choose L-Model, T-Model, Button Model or Ring-Model and so on.

RITEON quick release pin,ball lock pin,detent pin,self lock pin,positive lock pin Can be provided various forms of handle, and all kinds of specifications of metric and inch. the leadtime is very short. We always keep a large stock of, and also we have a technology department, the ministry of research design, a fully furnished equipment. RITEON's are standby to provide quality services to our clients.
