| Brand Name: | TreLink |
|---|---|
| Input connector type: | N Female |
| Lightning protection: | DC Ground |
| Gain(dBi): | 12 dBi |
| Frequency range(MHz): | 806-960 MHz |
| Model Number: | TLYA-890-12-12C |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
| Electrical Specifications | |
| Model | TLYA-890-12-12C |
| Frequency Range | 806-960 MHz |
| Gain | 12 dBi |
| VSWR | <2:1 |
| Polarization | Vertical |
| F/B Ratio | 18 dB |
| Horizontal Beamwidth | 36 |
| Vertical Beamwidth | 32 |
| Input Impedance | 50 |
| Maximum Power | 100W |
| Lightning Protection | DC Ground |
| Mechanical Specifications | |
| Connector | N Female |
| Antenna Dimension | 1420mm |
| Weight | 1.2 kg /2.6 lb |
| Reflector Material | Aluminum |
| Wind Velocity | 210 km/h |
| Working Temperature | -40~+65 |
| Mounting Pole | 38-52 mm |
