| Brand Name: | TreLink |
|---|---|
| Input connector type: | N Female |
| Lightning protection: | DC Ground |
| Gain(dBi): | 5 dBi |
| Frequency range(MHz): | 698-2700 MHz |
| Model Number: | TLOD-627-6V |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
| Electrical Specifications | ||
| Model | TLOD-627-6V | |
| Frequency Range | 698-960 MHz | 1710-2700 MHz |
| Gain | 5 dBi | 6 dBi |
| VSWR | 2.5:1 | |
| Polarization | Vertical | |
| Horizontal Beamwidth | 360 | |
| Vertical Beamwidth | 42 | 31 |
| Input Impedance | 50 | |
| Maximum Power | 50 W | |
| Lightning Protection | DC Ground | |
| Mechanical Specifications | ||
| Connector | N Female | |
| Antenna Dimension(diameter*length) | 52*990 mm | |
| Weight | 1. 6kg /3.52 lb | |
| Radome Material | Fiberglass | |
| Wind Velocity | 210 km/h | |
| Working Temperature | -40~+65 | |
| Mounting Pole | 38-60 mm | |
