| Brand Name: | TreLink |
|---|---|
| Input connector type: | N Female |
| Lightning protection: | DC Ground |
| Gain(dBi): | 18dBi |
| Frequency range(MHz): | 5150-5850 MHz |
| Model Number: | TLSP-5158-18-60V |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
| Electrical Specifications | |
| Model | TLSP-5158-18-60V |
| Frequency Range | 5150-5850 MHz |
| Gain | 18 dBi |
| VSWR | <1.8:1 |
| Polarization | Vertical |
| F/B Ratio | >30dB |
| Horizontal Beamwidth | 60 |
| Vertical Beamwidth | 7 |
| Input Impedance | 50 |
| Maximum Power | 100W |
| Lightning Protection | DC Ground |
| Mechanical Specifications | |
| Connector | N Female |
| Antenna Dimension(length*width*height) | 465*135*40 mm |
| Weight | 1.5 kg /3.3 lb |
| Radome Material | ABS |
| Mounting Method | Mast |
| Wind Velocity | 210 km/h |
| Working Temperature | -40~+65 |
