Product Parameters                                                                                                         1.Chassis

Chassis model	EQ1070
Drive Type	4x2
Whelbase	2800, 3306mm
Top Speed	90km/h
Engine Type	(GB17691-2005,GB3847-2005)(diesel)(Euro 5)
Power	70kW

2.Driving room

Size(L*w*H)	6940*2280*2880
Structure	Flat head, four door double row cab
Seat set	3+2(Two people in the front row (including the driver) and three in the back)
Equipment	in addition to the original vehicle equipment, it is equipped with 100W alarm, rotary warning light switch, lever control switch and indicator light

 3.Volume of tank

Volume	Water tanker:2500L-35000L
Material	High quality carbon steel plate
Structure	Steel plate welded type, internal anti - swash plate
Equipment	1 population hole, with a quick locking and opening device  1 overflow device  1 level indicator  2 outlet, manual control valve
Technical requirements	Comply with the relevant provisions of GA39

 4.Fire pump

Model	CB10/30
Flow	30L/s
Pressure	1.0Mpa
Water diversion time	30s
Type of installation	Rear-mounted



5.Fire monitor

Model	SP30
Flow	30L/s
Range	more than 45m.
Pressure	1.0Mpa
Turning Angle	the level is greater than 270 degrees, and the pitch is -15 to 45 degrees.
