| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Production Capacity: | 5400 pcs/hour |
| Type: | Rotary Tablet Press |
| Brand Name: | China Tablet Press |
| Condition: | New |
| Dimension(L*W*H): | 1700*1280*2240mm |
| Weight: | 7500kg |
| Power(W): | 22kw |
| Voltage: | 380v |
| Max. Tablet Diameter(mm): | 80 |
| Max. Tablet Thickness(mm): | 28 |
| Max. Pressure(KN): | 1000 |
| Model Number: | ZPS100-10C |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Max working pressure: 1000KN
Max pre-working pressure: 200KN
Max diameter of tablet: 80mm
Max thickness of tablet: 28mm
Max depth of filling: 60mm
Dies: 10 sets
Max production capacity: 5400pcs/h
Rotation Speed: 0~9 r/min
Outer diameter of upper mould: 90mm
Height of middle mould: 70mm
Diamer of upper & bottom punch pole: 80 mm
Motor power: 22kw
Voltage 380/50 V/Hz
Machine Weight: 7500kg
Machine overall size: 1700*1280*2240mm (not including hopper)
Max pre-working pressure: 200KN
Max diameter of tablet: 80mm
Max thickness of tablet: 28mm
Max depth of filling: 60mm
Dies: 10 sets
Max production capacity: 5400pcs/h
Rotation Speed: 0~9 r/min
Outer diameter of upper mould: 90mm
Height of middle mould: 70mm
Diamer of upper & bottom punch pole: 80 mm
Motor power: 22kw
Voltage 380/50 V/Hz
Machine Weight: 7500kg
Machine overall size: 1700*1280*2240mm (not including hopper)
