| Measurement Range: | 30-10000m |
|---|---|
| Measurement Accuracy: | 0.5m |
| Size: | 115 mm * 152 mm * 54 mm |
| Brand Name: | DRJ01000B |
| Gross Weight: | 1kg |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Specific Index
1) DRJ01000B(KJ01000) hand-held laser rangefinder, is a kind of new photoelectric observation products with light, machine, electricity, and laser as one and it has the function of a telescope and laser rangefinder. In the observation of the inside object, at the same time, we can measure the target distance. It is characterized by small volume, light weight, high precision, simple operation, reliable performance, easy to carry and small power consumption.
2) this one mainly used for field observation target and quickly, accurately measuring the distance to the selected target. Can be widely used in military, engineering construction, field entertainment observation activities, and also can be used for the general topographic survey.
Cooperated Organizations
the main technical index |
Details: |
Wavelength |
1064nm (ND: YAG) |
Max ranging |
10000m |
Ranging accuracy |
0.5m |
Ranging gating |
20-5120m (Step length is 10 m) |
Measuring accuracy |
98% |
Repeat frequency |
1/6 ~ 1/3 Hz(10-20times/min) |
Receiving caliber |
30mm |
Field of view |
6.5 |
Ranging resolution |
35 m |
Visual magnification |
7x |
Output interface |
RS232,2400,8,N,2 |
-10C~+50C Operation temperature |
Dustproof, waterproof, shockproof |
Dimensions |
115*152*54mm |
Weight |
1Kg |
Data storage (1000 data) | |
Working life add up of the instrument | |
Query the recent ten times value range | |
LCD screens and reticle brightness control, without any operation in the 20s, the screen will be closed automatically | |
Polymer lithium battery (11.1V, 3000 mA), at room temperature, each battery pack can work 20000 times. | |
